Glass drilling machine HD-0222

Daks-96 offers double headed drilling machines for glass.

The glass drilling machine model HD-0222 uses a pneumaticgripand dual drill head.

The glass positioning is done via a laser positioning system, the drilling itself is done simultaneously on the top and bottom of the glass thanks to the dual drilling head of the machine.

The operation platform can be pneumatically elevated or lowered. The machine can be semi-automatically controlled and automatically controlled.

Техническа спецификация

Drilling diameter: Ф4– 220 mm
Glass thickness: 3 – 25 mm
MAximum work dimension glass: 2500 x 2500 mm
Power: 2,5kw380V/50Hz
Weight: 950 kg.
Machine dimensions: 2200 x 2200 x 1700 мм (L x W x H)
Work table dimensions: 2200 x 1600 mm
